SonoScape E2V

Our most popular first opinion scanner for small animal work, the SonoScape E2V is a mid-range, portable, colour doppler scanner. A comprehensive range of probes is available for abdominal, cardiac, ocular, and MSK sonography. Ideal for general small animal work and priced to suit most budgets.

Probes

Micro-convex
C613 (4-13MHz) – small dog and cat abdomen and basic cardiac
C322 (2-7MHz) – medium and large dog abdomen and basic cardiac

Linear
L741 (4-16MHz) – MSK, high definition abdomen
10I2 (4-16MHz) – exotics, ocular

Phased array
7P-B (2-9MHz) - cardiac

Features

Light weight and compact
2 transducer ports
Quick boot up
Auto image optimisation - enhance your images with one button
Wide scan – enlarge image area
µ-Scan – Speckle Reduction and Edge Enhancement
2 year warranty on scanner and probes
Excellent range of programmable presets
Different probe combinations can be provided and additional probes can be added as required
Measurements include distance, eclipse and trace
Integral battery with approximately 90 minutes operating life
DICOM transmissions and worklist
Carrying case as standard, trolley and foot switch available as optional accessories
In house technical training provided

Technical Specification

Multi-beam processing technology
µ-Scan – speckle reduction and edge enhancement
Spatial compound imaging
Tissue harmonic imaging
HD zoom – enlarge image area
M-Mode, Color/PW/CW/Power Doppler
Chroma – highlight image details
B Steer for linear probe
Quick boot up
Auto brightness adjustment
Auto image optimisation
Auto Trace
Light weight and compact
15.6" High Resolution LCD color monitor (with auto-adaptive LED backlight)
Wide folding range and viewing angle
Extended connector available for up to 3 probes
Backlit keyboard and intelligent panel
Battery extender – up to 3 hours
2 year warranty of scanner and probes

Downloads

E2V Catalogue

Full Technical Specification

CPD

We offer veterinary ultrasound CPD including online ultrasound courses, practical ultrasound workshops and in-house training - click here to visit our Veterinary Academy

Training and CPD

All purchases come with in depth training, and ongoing support to ensure you get the best results from your SonoScape scanner. Required pre-sets will be programmed at install and additional CPD is available on a one-to-one or group basis.

Find out more

Servicing

All our scanners require regular servicing, our dedicated team of engineers are able to service units at a time convenient for you to ensure your machine remains in top condition.

Find out more
